Metal 3D laser printer
Humanized design, operation interface visualization, humanization; easy operation and maintenance, double filtration system, good process safety; high molding accuracy, self-designed light path system, excellent wind farm design to ensure high molding accuracy and molding parts performance;
According to different printing materials and parts, scraper blades of different materials can be selected; two-way powder laying, 2-galvanometer;
Humanized design, visual and user-friendly operation interface; easy operation and maintenance, double filtration system, good process safety;
High molding accuracy, self-designed optical path system and excellent wind field design ensure high molding accuracy and forming part performance.
The optimized design of the wind farm structure ensures the effective removal of dust and spatter, and the printing of the full-width parts is uniform.
The self-developed process software optimizes the scanning path and shortens the processing time; the open system of multi-material and multi-process can configure the process parameter package of different materials;
The system automatically logs the detailed processing process, and records the layer number, part temperature, cabin pressure, oxygen content, molding cylinder position, material cylinder position, powder laying cart position, processing time, etc. during the part printing process to ensure the high quality performance of the product.
| Model | GT360 |
|---|---|
| Device size | 2200mmx1500mmx2450mm |
| Forming size | 350mmx350mmx300mm |
| forming accuracy | ±0.05 mm |
| Powder supply method | powder topping |
| powder thickness | 20 ~ 100 μm |
| Light spot diameter | 75 μm |
| Laser power | 500W*2 |
| scanning speed | 9m/s |
| forming speed | 25-70cm3/h |
| oxygen content | ≤100ppm |
| Gas protection | N2/Ar |
| Overall weight | 2800KG |
| Power consumption of the whole machine | 8KW |
| software | Magic + BP, 3DXpert |
| data format | STL\ OBL\ STEP and other data formats |
| Applicable materials | Stainless steel, die steel, cobalt-chromium alloy, superalloy, titanium alloy, aluminum alloy, etc |
