Portable Marking Machine - Professional Edition
Handheld laser marking machine, specially designed to solve various marking difficulties. Advanced laser technology is used to achieve fast focusing and high-precision marking. Highly integrated design, small and lightweight body, detachable design of battery, can have unlimited battery life and improve work efficiency. Handheld laser marking machine has a wider range of use and higher flexibility, which can meet the daily needs of customers.
Product model: DA-DAW-20/30/50
Laser power: 20W/30W/50W
Handheld laser marking machine, specially designed to solve various marking difficulties. Advanced laser technology is used to achieve fast focusing and high-precision marking. Highly integrated design, small and lightweight body, detachable design of battery, can have unlimited battery life and improve work efficiency. Handheld laser marking machine has a wider range of use and higher flexibility, which can meet the daily needs of customers.
core features
application field
Metal processing and manufacturing
- Hardware/tool industry: Stainless steel, iron, copper, aluminum and other materials can be used to mark the brand, specification and traceability code of wrenches, screwdrivers, molds and fasteners.
- Automotive manufacturing industry: engine block, transmission gear, aluminum parts, rubber seals, plastic interior parts and other key components require laser marking to achieve permanent traceability.
- Electronic and electrical industry: stainless steel shell, aluminum heat sink, plastic button/shell, copper terminals, etc., used to mark the model, serial number, QR code and other information.
Packaging and Consumer Goods Industry
- Food/medicine/daily chemical packaging: cartons and lacquered label paper can be directly marked with the production date, batch number, and anti-counterfeiting code, which are commonly found in the outer packaging of snacks, medicines, and cosmetics.
- Luxury goods and gifts industry: lacquered glass (e.g. perfume bottles, tableware), laser engraving patterns for metal jewelry, and brand logos to enhance product texture and anti-counterfeiting.
Other key application industries
- Medical apparatus industry: stainless steel surgical instruments, plastic supplies sterilization identification, batch number, in line with hygiene and traceability requirements.
- Rubber and plastic products industry: rubber seals, plastic pipes, cable sheath specifications, temperature grade marking, commonly found in construction, home appliances, automotive fields.
- Logistics/warehousing industry: Barcode/QR code marking of painted label paper and cartons for logistics tracking and inventory management.
| Model | DA-DAW-20/30/50 |
|---|---|
| laser | Fiber laser generator |
| output power | 20W / 30W / 50W |
| Marking range | 7070Mm/100100mm (optional) |
| Deflecting mirror | High-precision 3D scanning system |
| laser wavelength | 1064nm |
| Focusing lens | F130 |
| Marking speed | ≤7000mm/s |
| master control | Integrated main board, 8 inch capacitive full fit screen |
| Operating System | Linux system |
| Marking line type | Dot matrix, vector machine |
| line width | 0.03mm |
| repeatability | 0.01mm |
| positioning method | Red light positioning, focusing |
| Number of lettering lines | Any line within the effective marking range |
| Print speed | 800 characters (related to material and print content) |
| font | Chinese and English, numbers, traditional Chinese and other standard fonts |
| file format | BMP、DXF、HPGL、JEPG、PLT |
| barcode | CODE39、CODE128、CODE126、QR |
| power supply | 110V/220VAC/lithium battery (216wh) |
| Power consumption of the whole machine | 145-250W |
| Operating temperature of the whole machine | 0-40℃ |
| Overall weight | 6~ 6.8Kg (plug-in version, lithium battery version) |
| FCL weight | Power supply 8.7Kg Battery 9.7Kg |
| Outer packing box size | 520415305Mm (length, width and height) |
